ACCUMULATOR

The bearings connected to the elevator pulleys will be with linear bearings.

The lifting-lowering system connected to the elevator pulleys will be pneumatic.

Elevator pulley bearings with linear bearing.

Elevator air pressure control will be with UP Regulator, fine adjustment from operator panel.

Elevator lifting-lowering system with 16B single-row chain system.

Air tank will be CE certified.

Valve check valve will be used for quick air discharge.

10+9 pulleys.

Pulley diameters: 400mm.

Storage capacity: 40 meters.

Elevator stroke distance: 3 meters.

Rubber end stops on the top and bottom of the elevator for min and max limits.

Min and max level sensors for safety.

Reducer-based distance reading system will be used for elevator stroke reference.

360° rotatable guiding pulley group at the elevator entry of the pay-off and the elevator exit of the take-up.

Rubber pneumatic cable clamp at the pay-off elevator entry and at the take-up elevator exit.

Both pay-off elevator pressure and take-up elevator pressure can be precisely adjusted from the operator panel.

Protective cage and safety system.
